    Our Products

    22A-4 Agricultural Spaying Drone

    • Spay Smog Type: Install spray system with 6 screws on elevated shelf, then can be spay smog, easy to change
    • Spray Fertilizer Type:  install spray fertilizer system on drone, connect electric & signal wire, test , then can be work
    • Spray Liquid Pesticide Type:  (1) spray 3-6m, low request of takeoff and landing place.(2) High efficient 110 degree sector nozzle (3) operate easy, support automated fly (4) support crosswise foldable, easy to transport.
    Dimension2100*2100*660mm
    Wheelbase1700mm
    Working Speed4-8m/s
    Spraying Width4-6m
    Pressure nozzle number6 pcs
    Operating Efficiency100mu/h
    Max. Takeoff Weight40kg
    Pesticide Container Capacity22L
    Polymer Lithium Battery Capacity12000mAh*4
    Operating Time>=12min
    Flying Altitude2-8m

    22A-6 Agricultural Spaying Drone

    • The capacity of pesticide box is 20L, anti-fluctuate design.
    • Lateral folding, easy to carry.
    • Filtering air to cooling motor, effectively avoiding pesticide corrosion. Flight control support autonomous fight and real-time voice broadcasting
    Dimension3700*2100*620mm
    Wheelbase2940mm
    Working Speed4-8m/s
    Spraying Width8-12m
    Pressure nozzle number10 pcs
    Operating Efficiency170 mu/h
    Max. Takeoff Weight43kg
    Pesticide Container Capacity22L
    Polymer Lithium Battery Capacity6s 12000*4mAh

    30A Agricultural Spaying Drone

    • The capacity of pesticide box is 30L, anti-fluctuate design.
    • Lateral folding, easy to carry.
    • Filtering air to cooling motor, effectively avoiding pesticide corrosion.
    • Flight control support autonomous fight and real-time voice broadcasting.
    Dimension2620*2670*500mm
    Wheelbase2028mm
    Working Speed4-8m/s
    Spraying Width6-8m
    Pressure nozzle number8 pcs
    Operating Efficiency200 mu/h
    Max. Takeoff Weight50kg
    Pesticide Container Capacity30L
    Polymer Lithium Battery Capacity14s 28000*2mAh

    50A Agricultural Spaying Drone

    • Using a detachable 4-motor design, which is convenient for maintenance ;
    • Centrifugal nozzle ;
    • The whole machine uses an intelligent control system ;
    • With ground-like flight and automatic obstacle avoidance functions;
    Dimension2845*2718*830mm
    Wheelbase2272mm
    Working Speed4-8m/s
    Spraying Width6-8m
    Pressure nozzle number4 pcs
    Operating Efficiency200 mu/h
    Max. Takeoff Weight90kg
    Pesticide Container Capacity50L
    Polymer Lithium Battery Capacity18s 30000*2mAh
